Wac Lighting FM-W47206-30-BK Downtown Square Outdoor Ceiling Mount 11.9W 5 Inch

Product Description

The WAC LIGHTING FM-W47206-30-BK Downtown Square Outdoor Ceiling Mount is a versatile 5-inch lighting fixture designed for both interior and exterior ceiling or wall installations. Constructed with a durable aluminum body and glass diffuser, it features ACLED driverless technology and offers built-in color temperature adjustability between 3000K, 3500K, and 4000K. Operating at 120 VAC with 11.9W power, it delivers up to 795 lumens with a 90 CRI and a 54000-hour rated life. It is ETL/cETL listed for wet locations and Title 24 compliant.

• Built-in color temperature adjustability, allowing selection between 3000K, 3500K, and 4000K.
• Utilizes ACLED driverless technology, eliminating the need for an external driver or transformer.
• Smooth and continuous dimming capability with electronic low voltage (ELV) or TRIAC dimmer options.

Product Highlights

This 5-inch square fixture is wet rated for direct exposure to rain and moisture, making it suitable for diverse indoor and outdoor applications.

Product Information

Standard Information

• Brand: WAC LIGHTING
• Manufacturer Part Number: FM-W47206-30-BK
• Country of Origin: USA Assembled

Technical Specifications

• Size: 5 Inch
• Color Temperature: 3000K, 3500K, 4000K
• Finish: Black
• Delivered Lumens: Up to 795 lm
• CRI: 90
• Power: 11.9W
• Input Voltage: 120 VAC
• Dimming Range ELV: 100-10%
• Dimming Range TRIAC: 100-10%
• Rated Life: 54000 Hours
• Construction Material: Aluminum, Glass
• Mounting Type: Flush Mount
• UPC: 790576880815
• Dimmable: Yes
• Light Source: LED
• Number of Lights: 1
• Bulb Type: Integrated LED Module
• Bulbs Included: Yes
• LED Type: Integrated LED
• Socket Type: LED Module - ACLED Module
• Country of Origin: USA Assembled
• Dark Sky Compliant: Yes
• Title 20 Compliant: Yes
• Title 24 Compliant: Yes
• Certifications: ETL/cETL, IP65 Wet Rated
• Installation Type: Hardwired
• Sloped Ceiling Compatible: Yes
• Maximum Slope Angle: 90 Degrees
• Diffuser Color: Clear
• Efficacy: 63.45 Lumens/Watt
• Shape: Square
• Diffuser Finish: Frosted
