Vybond 555-METALLIC_3X120YD Metallic Film Tape 3in X 120YD

Product Description

The VYBOND 555-METALLIC_3X120YD is a metallic printed OPP film tape with an acrylic adhesive system, engineered for HVAC duct sealing, dryer vent connections, and reflective insulation patching. The tape measures 3 inches wide and runs 120 yards per roll at 3.1 mil thickness. It carries a UL 181B-FX listing, making it code-compliant for flexible duct sealing applications. The acrylic adhesive is solvent-free and low in VOC content, which supports LEED compliance for both EA Credit 1 and EQ Credit 4.1. HVAC technicians and insulation contractors are the primary installers. The hand-tearable backing speeds up fieldwork without requiring a dispenser gun on every job.

This tape is suited for residential and light commercial HVAC installations where a UL 181B-FX listed product is required by code. Typical applications include sealing flexible and rigid duct connections, patching reflective bubble insulation materials, and securing dryer vent connections. The metallic finish with high-visibility print allows inspectors to quickly identify taped joints during inspection. The mold- and moisture-resistant construction makes it appropriate for installations in unconditioned spaces, crawlspaces, and attics where humidity exposure is common.

Key Features

• UL 181B-FX listed for use on flexible duct systems per code requirements
• Solvent-free acrylic adhesive with low VOC content supports LEED EQ Credit 4.1 compliance
• Rated for service from -40 degrees F to 212 degrees F for use across a wide installation range
• Hand-tearable OPP film backing eliminates the need for a tape dispenser on the job
• High-visibility metallic finish with contrasting print for straightforward field inspection
• Mold and moisture resistant construction for unconditioned space installs

Compatibility

Designed for use on flexible duct connections, dryer vent connections, and reflective or bubble insulation materials in residential and commercial HVAC applications where UL 181B-FX listed tape is specified.

Installation Notes

Installation should be performed by a licensed HVAC technician or insulation contractor in accordance with local mechanical codes and SMACNA guidelines. Shut down the HVAC system before accessing duct connections or vent terminations. Surfaces should be clean, dry, and free of dust or grease before applying tape to ensure full adhesive contact. Follow local Authority Having Jurisdiction requirements for duct sealing materials and listed product usage.

Technical Specifications

• Type: Film Tape, 1-Coated
• Color: Metallic
• Width: 3 inches
• Length: 120 yards per roll
• Thickness: 3.1 mil
• Backing Material: Printed OPP Film
• Adhesive: Acrylic
• Temperature Rating: -40 to 212 degrees F
• Applicable Standards: UL 181B-FX, PSTC-101, LEED

Standard Information

• Brand: VYBOND
• Manufacturer Part Number: 555-METALLIC_3X120YD
