Vybond 223S2 Gray Cloth Duct Tape 10 Mil 2 in X 60 Yd

Product Description

The VYBOND 223S2 is a multi-purpose cloth-backed duct tape built for HVAC, insulation, and general construction applications. It uses a polyethylene-coated cloth backing paired with a natural rubber adhesive that delivers approximately 50 oz/in of adhesion to steel. Total tape thickness is 10 mils, and the operating temperature range runs from 40 degrees F to 200 degrees F. The 2-inch width and 60-yard roll length provide efficient coverage on larger jobs. HVAC technicians, insulation installers, and general tradespeople reach for this tape when they need a conformable, reliable hold on irregular or flat surfaces.

This tape suits a wide range of jobsite tasks including HVAC duct sealing, insulation blanket holding, bundling of pipes or conduit, and general repair work. The conformable cloth backing allows it to wrap around curved or uneven surfaces without lifting at the edges. It maintains contact on sheet metal, rigid and flexible insulation, and other common substrate materials encountered in residential and light commercial mechanical rooms and utility spaces.

Key Features

• Natural rubber adhesive with approximately 50 oz/in adhesion to steel
• PE-coated cloth backing conforms to irregular and curved surfaces
• 10 mil total thickness for durable, tear-resistant performance
• Operating temperature range of 40 degrees F to 200 degrees F
• 2-inch width and 60-yard roll length for efficient, large-area coverage
• Suitable for duct sealing, insulation holding, bundling, and repair tasks

Compatibility

Designed as a general-purpose cloth duct tape for use on sheet metal ductwork, rigid and flexible insulation, and common construction substrates in HVAC, plumbing, and general mechanical applications.

Installation Notes

Surface preparation is critical for adhesive performance — clean and dry all substrates before applying the tape to remove dust, oil, and moisture. Apply firm hand pressure across the full tape width to ensure complete contact, especially on curved or textured surfaces. This tape is intended for general mechanical and construction use; where pressure-sensitive tape is required for rated duct sealing, verify local code compliance with UL 181 or applicable SMACNA standards before use.

Technical Specifications

• Color: Gray
• Backing Material: PE-coated cloth
• Adhesive Type: Natural rubber
• Adhesion to Steel: Approximately 50 oz/in
• Total Thickness: 10 mil
• Width: 2 inches
• Roll Length: 60 yards
• Operating Temperature Range: 40 degrees F to 200 degrees F
• Quantity per Unit: 1 roll

Standard Information

• Brand: VYBOND
• Manufacturer Part Number: 223S2
