Von Duprin PS914-2RS Power Supply 4 Amp

Product Description

The Von Duprin PS914-2RS is a power supply designed for panic exit applications with high in-rush current needs. This unit provides a filtered and regulated output to ensure the reliability of connected devices. It can manage a variety of electrified latch retraction devices, making it versatile for different installations.

• 4-amp Class 2 filtered and regulated power.
• Consistent power output that protects sensitive circuits.
• Overload protection for safe operation with multiple devices.

Product Highlights

The PS914-2RS power supply is essential for maintaining functionality in emergency exit systems.

Product Information

Standard Information

• Model: PS914
• Brand: Von Duprin

Technical Specifications

• Input Voltage: 120/240 VAC, 50/60 Hz
• Output Voltage: 12 or 24 VDC, field selectable
• Operating Temperature: 32 to 120 F (0 to 49 C)
• Cabinet Dimensions: 14 inches H x 12 inches W x 4 inches D
• Certifications: UL 294, ULC-S318, RoHS, FCC Part 15
• Power Source: Hardwired
• Output Amps: 4 AMPS
