Von Duprin 9947EOF26D3 Concealed Vertical Rod Exit Device

Product Description

The VON DUPRIN 9947EOF26D3 is a fire-rated concealed vertical rod exit device designed for single-door commercial applications requiring compliant emergency egress hardware. Built with a grooved case profile, it conceals the vertical rod mechanism within the door for a clean installation. The 626 Satin Chrome finish provides corrosion resistance suited to high-traffic public and institutional environments. At 36.75 inches in length, this unit fits standard 3-foot door preparations. Licensed locksmiths, door hardware specialists, and commercial contractors typically specify and install this device on rated door assemblies.

This exit device is intended for commercial and institutional buildings where fire-rated egress hardware is required by code. Typical applications include corridors, stairwells, and exit passageways in schools, hospitals, government facilities, and office buildings. The concealed vertical rod design suits applications where exposed rods are not acceptable for aesthetic or operational reasons. The EOF designation indicates an end-of-run frame configuration, which is relevant when specifying the device for specific frame and door preparations.

Key Features

• Fire-rated construction meets requirements for rated door assemblies in commercial egress applications
• Concealed vertical rod mechanism with grooved case keeps hardware protected and visually clean
• 626 Satin Chrome finish provides durable, low-maintenance corrosion resistance
• 36.75-inch length sized for standard 3-foot door openings
• EOF (end-of-run frame) configuration for proper frame alignment during installation
• Sold individually as a single-unit sales item

Compatibility

Designed as an OEM-style fire-rated concealed vertical rod exit device for commercial single-door egress applications on standard 3-foot door preparations with compatible rated frames.

Installation Notes

Installation should be performed by a licensed door hardware technician or commercial contractor familiar with NFPA 80 requirements for fire-rated door assemblies. Verify that the door, frame, and hardware are all listed and labeled as compatible components for the required fire rating before installation. De-energize any connected access control or electrified hardware at the panel before working on the device. Follow the manufacturer installation instructions for rod adjustment and case alignment to ensure proper latching and code-compliant operation.
