VON DUPRIN 98EO-F-626-48 Rim Panic Device Exit Only 48inch

Product Description

The VON DUPRIN 98EO-F-626-48 is a rim exit device designed for exit-only use. It is suitable for fire-rated applications and meets rigorous safety standards. This device is non-handed, making it versatile for various installations. It is UL listed for panic and fire hardware, complying with ANSI A156.3, 2001, Grade 1.

• Grade 1 rim exit device
• Designed for exit-only functionality
• UL listed for fire-rated applications

Product Highlights

The VON DUPRIN 98EO-F-626-48 provides reliable access control while maintaining safety standards. It features a smooth mechanism case for easy operation.

Product Information

Standard Information

• Device Function: EO - Exit Only
• Handing: Field Reversible

Technical Specifications

• Device Lengths: 48 inches
• Door Size: 48 inches wide
• Device Centerline from Finished Floor: 39 13/16 inches
• Center Case Dimensions: 8 inches x 2 3/4 inches x 2 3/8 inches
• Mechanism Case Dimensions: 2 1/4 inches x 2 1/4 inches
• Latch Bolt Throw: 3/4 inch
• Projection: Pushbar neutral 3 13/16 inches, depressed 3 1/16 inches
• Fasteners: Includes screw pack for installation
