Vigitron Inc. VI30002U 10/100 Managed Ethernet Poe++ 90W

Product Description

The VIGITRON INC. VI30002U is a 10/100 managed Ethernet Power over Ethernet injector rated at 90 watts, designed to deliver high-power PoE++ to connected devices over standard network cabling. This unit supplies both data and DC power through a single Ethernet connection, eliminating the need for separate power supplies at the endpoint. It is suited for powering demanding network devices such as PTZ cameras, wireless access points, and video intercoms. Installation is typically handled by low-voltage technicians or network integrators working in commercial or industrial environments.

The VI30002U is designed for use in applications where high-wattage PoE delivery is required over 10/100 Ethernet infrastructure. It fits into commercial security, access control, and building automation installations where endpoint devices exceed the power limits of standard PoE or PoE+ standards. The unit is sold individually and is appropriate for both new installations and retrofit scenarios where existing cabling is already in place.

Key Features

• 90-watt PoE++ output supports high-draw endpoint devices
• 10/100 Ethernet data pass-through with simultaneous power delivery
• Managed configuration for monitoring and control of power output
• Single-port injector allows targeted deployment without a full switch replacement
• Sold as a single unit for flexible, as-needed installation

Compatibility

Designed as an OEM-style PoE++ injector for use with IEEE 802.3bt-compatible endpoint devices requiring up to 90 watts over standard Ethernet cabling.

Installation Notes

Installation should be performed by a qualified low-voltage technician or network integrator familiar with PoE power budgeting and structured cabling standards. Verify that the connected endpoint device and cabling plant are rated to handle 90-watt PoE++ delivery before energizing. Do not connect to endpoints that do not support PoE++ negotiation, as improper pairing can damage equipment. Reference TIA-568 cabling standards and local low-voltage codes for cable type and run-length requirements.
