Viessmann 7722775 Vitodens 100-W Natural Gas Boiler Heat Only 199K BTU

Product Description

The Viessmann 7722775 Vitodens 100-W is a gas-fired wall-mounted condensing boiler featuring a modulating MatriX-Plus cylinder burner and an Inox-Radial heat exchanger made of stainless steel. The Vitodens 100-W boiler combines value, quality, and Viessmann technology. It is designed for fast and easy installation, service, and maintenance.

• Outstanding efficiency of 95.0% AFUE on all models.
• Lasting performance with Viessmann-made stainless steel Inox-Radial heat exchanger.
• Low-emission operation with fully-modulating stainless steel MatrixPlus cylinder burner.

Product Highlights

The Vitodens 100-W offers 95% efficiency, a stainless steel heat exchanger, and a low-emission burner in a compact, wall-mounted design.

Product Information

Standard Information

• Brand: VIESSMANN
• Manufacturer Part Number: 7722775

Technical Specifications

• MPN: 7722775
• Manufacturer: Viessmann
• Series: B1HE
• BTU Input: 199,000
• AFUE: 95%
• Height (Inches): 39"
• Width (Inches): 17.75"
• Depth (Inches): 21.75"
• Material: Stainless Steel
• Fuel Type: Natural Gas/Liquid Propane
• Venting Type: Direct Vent
• Connection Type: 3/4 in FNPT
• Input Capacity: 199,000 BTU/hr
• Type: Condensing
• AFUE Rating: 95%
• Commercial / Residential: Residential
• Gas Supply Pressure: 4 Min / 14 Max w.c.
• Heat Exchanger Surface Area: 27.44 sq. ft
• Mounting Type: Wall
• Net AHRI Rating: 163 MBH
• Output Capacity: 187,000 BTU/hr
• Pressure Rating: 60 psig
• Sound Level: 55 dBA
• Temperature Rating: 68 to 210 deg F
• BTU Output: 187000
• Annual Fuel Usage Efficiency (AFUE): 95.0
• Domestic Hot Water: No
• Building Type: Residential
• Vent Material: PVC/CPVC
• Supply: Male Iron Pipe 1
• Return: Male Iron Pipe 1
• Gas Connection (inches): 3/4
• Vent Size (inches): 3
