Viega 95195 Megapress Reducing Tee 1x3/4 Inch 304SS

Product Description

The VIEGA 95195 is a MegaPress reducing tee fitting designed for stainless steel press-fit piping systems. Constructed from 304 stainless steel, it connects 1-inch press ends to a 3/4-inch female threaded outlet, making it a practical transition fitting for piping configurations that require both press and threaded connections in a single assembly. The FKM sealing element is integrated into the fitting and provides a reliable seal during the press operation. This fitting is installed by licensed plumbers and pipefitters using a compatible press tool and jaw set rated for MegaPress fittings.

The 95195 is suited for commercial and industrial plumbing applications where stainless steel piping is specified. The reducing configuration handles branch takeoffs or transitions from a 1-inch main line to a 3/4-inch threaded connection point. Typical installations include mechanical rooms, process piping, and hydronic systems where corrosion resistance and joint integrity under pressure are required. The press-by-female-thread end configuration supports inline connections to threaded valves, gauges, or other threaded components without additional adapters.

Key Features

• 304 stainless steel construction for corrosion resistance in demanding piping environments
• MegaPress press-fit ends eliminate open-flame soldering for faster, cleaner installation
• Integrated FKM sealing element rated for use with the MegaPress system
• Reducing tee geometry transitions from 1-inch press to 3/4-inch female thread in one fitting
• Compatible with standard MegaPress press tools and jaw sets

Compatibility

Designed for use with the VIEGA MegaPress stainless steel press-fit piping system. Suitable for 1-inch x 3/4-inch reducing tee applications requiring a press-by-female-thread end configuration in 304 stainless steel piping assemblies.

Installation Notes

Installation must be performed by a qualified plumber or pipefitter using a press tool and jaw set approved for the MegaPress system. Shut off and depressurize the piping system and verify the line is dry before pressing. Do not use this fitting with non-press connection methods. Verify local plumbing code requirements, including applicable IPC provisions, before installation.

Technical Specifications

• Fitting Material: 304 Stainless Steel
• Fitting Size: 1 inch x 3/4 inch
• System: MegaPress
• Type: Reducing Tee
• End Connections: Press x Press x Female Thread
• Seal Material: FKM

Standard Information

• Brand: VIEGA
• Manufacturer Part Number: 95195
