Viega 94772 Propress Zero Lead Copper Tee 2x2x1 Inch

Product Description

The VIEGA 94772 is a zero-lead copper reducing tee fitting in the ProPress press-to-connect system, sized at 2 inches by 2 inches by 1 inch with three press-end connections. It is designed for licensed plumbers working in residential, commercial, and industrial piping systems who need a fast, solderless method to join or branch copper pipe. The fitting weighs 0.85 pounds and measures 3.19 inches by 2.01 inches by 5.00 inches. Connections are completed in four to seven seconds using a standard ProPress tool, eliminating the need for solder, flux, torches, or open flame on the job site.

The 94772 is suited for any new construction or retrofit application where copper distribution piping is used. Its press-to-connect design is particularly effective for maintenance and repair scenarios where wet or damp lines make torch-based soldering impractical or unsafe. The fitting is adaptable across residential potable water systems, commercial plumbing, and light industrial piping, making it a versatile component for service contractors and mechanical plumbers alike.

Key Features

• Zero-lead copper construction meets strict potable water material requirements
• Press connections made in four to seven seconds for fast, consistent installation
• Accepts wet connections, enabling repairs without fully draining the line
• Smart Connect feature identifies any unpressed connections during pressure testing so none are missed
• Eliminates solder, flux, torches, thread cutters, tanks, and hoses from the workflow
• Heavier copper wall than Type K, per manufacturer specification

Compatibility

Designed for use with the Viega ProPress press-to-connect system for copper pipe in 2-inch by 2-inch by 1-inch press configurations across commercial, industrial, and residential applications, whether new installation or retrofit.

Installation Notes

Installation must be performed by a licensed plumber using a compatible ProPress pressing tool and the correct jaw set for each pipe size. Shut off and depressurize the supply line before cutting and fitting the pipe, though the system does allow pressing on wet lines when full drainage is not possible. Verify all connections using the Smart Connect feature during pressure testing before returning the system to service. Follow all applicable local plumbing codes and IPC requirements for press-fit copper fittings.
