Viega 91545 PureFlow Press Adapter 1 inch x 3/4 inch

Product Description

The VIEGA 91545 PureFlow Press adapter connects 1" PEX pipe to 3/4" male threaded pipe using the Viega PEX press method. Made from lead-free bronze, it is approved for potable water use and compatible with all types of PEX tubing (A, B, C), including Viega oxygen barrier and plumbing tubing, as well as Viega FostaPEX.

• Connects 1" PEX pipe to 3/4" male threaded pipe
• Uses Viega PEX press method
• Made from lead-free bronze

Product Highlights

This Viega PureFlow Press adapter is suitable for use with all ViegaPEX tubing products and can be installed with the same hand and power tools as other Viega press systems.

Product Information

Standard Information

• Brand: VIEGA
• Manufacturer Part Number: 91545
• Country of Origin: Germany

Technical Specifications

• Primary Vendor Part Number: 91545
• Product Dimension: 1'' x 3/4''
• Width: 1.535 inches
• Connection Type: P x FPT
• Material Type: bronze
• Height: 1.417 inches
• Length: 1.335 inches
• Domestic/Import: Import
• End Style: Press x FNPT
• Material: Bronze
• Nominal Size: 1 x 3/4 in
• Pressure Rating: 100 psi
• Series: PureFlow®
• Temperature Rating: 180 To 200 deg F
• Type: Zero Lead
• Warranty: Limited
