Viega 79045 RPP79045 1 Check Valve P x P Lead-Free

Product Description

The Viega 79045 is a one-inch check valve made from bronze, suitable for potable water applications. It features a spring type, providing silent operation with a low-pressure loss. The ProPress connection on both ends ensures a strong and reliable seal, making it easy to install even in wet conditions. This valve is compliant with several standards, ensuring safety and quality in installation.

• Nominal Size: 1 Inch
• Pressure Rating: 200 PSI, 400 PSI (WOG)
• Temperature Rating: 200 Degrees F

Product Highlights

This check valve is designed for low lead compliance and includes EPDM sealing elements to prevent leaks. It operates effectively under a cracking pressure rating of 0.5 PSI, ensuring reliable performance.

Product Information

Standard Information

• Brand: Viega
• MPN: 79045

Technical Specifications

• Body Material: Bronze
• Spring Material: Stainless Steel
• Seal Material: EPDM
• End Connection: ProPress x ProPress
• End to End Distance: 3.15 Inches
• Applicable Standard: ABS, NSF 61G/372, CRN 0A14541.5 A/B/C
• Inclusions/Features: Low Pressure Loss, Silent Operation
