Viega 28502 MegaPress 28502 Model 4875.8 3-Piece Ball Valve 250 PSI 1 in Nominal

Product Description

The Viega 28502 is a MegaPress 3-Piece Ball Valve designed for use in various plumbing applications. It features a nominal size of one inch and is built with a 316 stainless steel body. This valve uses a press connection system, ensuring a secure fit with carbon steel pipes ranging from schedule five to schedule forty.

• Full port design for maximum flow
• Operates safely at a pressure rating of two hundred fifty psi
• Includes EPDM softgoods for reliable sealing

Product Highlights

The Viega MegaPress 28502 is ideal for a wide range of fluids, including water, diesel fuel, and low-pressure steam. The valve is equipped with a locking handle for easy operation and maximum control.

Product Information

Standard Information

• Brand: Viega
• Series: Model 4875.8

Technical Specifications

• Material: 316 stainless steel valve with carbon steel press ends
• Actuator Type: Locking handle
• Body Material: 316 stainless steel
• Ball Material: 316 stainless steel
• Pressure Rating: 250 psi
• Softgoods Material: EPDM/PTFE
• Temperature Rating: 0 to 250 degrees Fahrenheit
• Nominal Size: 1 in
• Port Type: Full
• Finish: Zinc nickel coated
