Viega 26775 MegaPress XL Flange Press 2-1/2 Inch

Product Description

The Viega 26775 MegaPress XL Flange is specifically designed for use with Schedule 5 to Schedule 40 carbon steel pipes. With a 2-1/2 inch diameter and a 4-bolt pattern, it ensures a reliable press connection. The flange is crafted from durable carbon steel and includes FKM sealing elements. This flange must be installed using MegaPress XL rings and a PressBooster/Z3 actuator.

• 2-1/2 inch diameter
• 4-bolt pattern
• Press connection with carbon steel

Product Highlights

This 2-1/2 inch MegaPress XL Flange by Viega merges durability with a secure press-fit connection, suitable for varied industrial applications.

Product Information

Standard Information

• Brand: Viega
• MPN: 26775

Technical Specifications

• UPC: 691514267753
• Material: Carbon Steel
• Application: Chilled Water, Hydronic Heating, Compressed Air, Fire Sprinkler
• Product Type: Press Flange
• Size: 2-1/2 inches
• Connection Type: Press x Press
• Pressure Rating: 200 PSI
• Flange Face Type: Flat Face
• Bolt Hole Diameter: 0.75 inches
• Standards: FM Class 1920, CRN OA14541.6, ICC LC1002, IAPMO PS 117, ASME B31, NFPA 13, 13D, 13R, 31, 54
• Weight: 8.157 lb
• Shipping Depth: 7.126 inches
• Shipping Width: 7.126 inches
• Shipping Height: 3.453 inches
• Max Operating Temperature: 284 Degrees F
• Min Operating Temperature: 14 Degrees F
• Finish/Coating: Zinc Nickel-Plated
• Origin: Germany
• Compatible Tools: MegaPress XL-Rings, Press Booster, MegaPress Z3-Actuator
