Viega 26685 MegaPress XL Coupling No Stop 26685-1 Each

Product Description

The Viega 26685 MegaPress XL Coupling without Stop is a reliable component designed for use with Schedule 5 to Schedule 40 carbon steel pipes. This coupling is crafted from carbon steel, ensuring durability and longevity in various applications including chilled water, hydronic heating, compressed air, and fire sprinkler systems.

• 2-1/2 inch pipe size
• Press connection
• Carbon steel material

Product Highlights

This coupling is ideal for non-potable water applications. It features FKM sealing elements and must be installed with MegaPress XL rings and PressBooster or Z3 actuator. Its construction supports ASTM A53, A106, A135, and A795 pipe standards.

Product Information

Standard Information

• Brand: Viega
• MPN: 26685

Technical Specifications

• Material: Carbon Steel
• Thread Size: 2-1/2 inch
• Thread Type: NPT
• Connector Type: Coupling
• Number of Pieces: 1
• Weight: 1.904 lb.
• Connection Size: 2-1/2 inch
• Connection Type: Press x Press
• Maximum Pressure Rating: 200 PSI
• Maximum Temperature Rating: 284 degrees F
• Minimum Temperature Rating: 14 degrees F
• Approvals: FM Class 1920, CRN OA14541.6, ICC LC 1002, IAPMO PS117, ASME B31, NFPA 13, 13D, 13R, 31, 54
