Viega 20201 Spring Check Valve 1/2 inches FPT

Product Description

The VIEGA 20201 spring check valve is designed for horizontal or vertical installation. Features an internal high-temperature plastic disk check and a solid brass body. This valve is suitable for residential, commercial, industrial, and radiant heating and cooling systems.

• Eliminates gravity circulation and backflow
• Compact design for easy installation
• Low pressure drop

Product Highlights

The VIEGA spring check valve offers a compact design and is suitable for various applications.

Product Information

Standard Information

• Brand: VIEGA
• Manufacturer Part Number: 20201
• Country of Origin: Italy

Technical Specifications

• Application: Residential, Commercial, Industrial, Radiant Heating and Cooling System
• Body Material: Solid Brass
• CATALOG NUMBER: 20201
• Category: Plumbing & Bath / Kitchen Fixtures
• Description: Check Valve; Type Spring, Horizontal/Vertical Mount; Nominal Size 1/2 Inch x 1/2 Inch; End Connection Female Threaded x Female Threaded; End to End Distance 1.875 Inch; Body Material Solid Brass; Disc Material High Temperature Plastic; Spring Material Stainless Steel; Temperature Rating 220 Deg F; Pressure Rating 150 PSI; Inclusions/Features Internal High Temperature Plastic Disk Check, Extremely Compact, Low Pressure Drop; Application Residential, Commercial, Industrial, Radiant Heating and Cooling System
• Disc Material: High Temperature Plastic
• End Connection: Female Threaded x Female Threaded
• End To End Distance: 1.875 Inch
• Features/Benefits: Eliminate Gravity Circulation and Backflow; Extremely Compact Design Make Installation Easy; Low Pressure Drop; Non-Ferrous
• Inclusions Features: Internal High Temperature Plastic Disk Check, Extremely Compact, Low Pressure Drop
• Manufacturer Name: Viega
• Manufacturer Part Number: 20201
• Nominal Size: 1/2 Inch x 1/2 Inch
• Pressure Rating: 150 PSI
• Series/Model: 2873.4US
• Spring Material: Stainless Steel
• Temperature Rating: 220 Deg F
• Type: Spring, Horizontal/Vertical Mount
• UNSPSC Code: 40141600
• Material: Bronze
• Inlet Size (inches): 1/2
• Inlet Connection: Female Pipe Thread
• Outlet Size (inches): 1/2
• Outlet Connection: Female Pipe Thread
• Check Style: Spring
• Height: 1.89 inches
• Width: 1.181 inches
• Length: 1.181 inches
• Product Dimension: 1/2'' x 1/2''
• Model Number: 2873.4US
• Connection Type: FPT1 x FPT2
• Product Type: Check Valve
