Victor 5645-8371 High Pressure Single Stage Gas Regulator

Product Description

The VICTOR 5645-8371 is a high pressure, single stage specialty gas regulator rated to 550 psi, built for demanding industrial gas service. The regulator features a brass forged body and housing cap, a stainless steel diaphragm, and a multi-seat block design for reliable pressure control. A nylon tee is included. UL Listed construction confirms the unit meets recognized safety standards. Licensed tradespeople and industrial gas technicians install this regulator where consistent high pressure regulation of specialty gases is required.

This regulator is suited for industrial applications where specialty gases must be delivered at controlled pressures. Single stage regulation simplifies setup in applications where inlet pressure is relatively stable. The forged brass body and stainless steel diaphragm provide durability in environments where corrosion resistance and mechanical integrity are priorities. Typical installations include laboratory gas systems, industrial process lines, and specialty gas distribution setups requiring high pressure handling up to 550 psi.

Key Features

• High pressure rating up to 550 psi for demanding industrial service
• Single stage regulation design for straightforward pressure control
• Brass forged body and housing cap for structural durability
• Stainless steel diaphragm for corrosion resistance and long service life
• Multi-seat block for consistent flow and pressure performance
• UL Listed for recognized safety compliance
• Nylon tee included

Compatibility

Designed as an OEM-style high pressure single stage regulator for industrial specialty gas systems requiring inlet pressure handling up to 550 psi.

Installation Notes

Installation should be performed by a qualified gas technician or pipefitter familiar with high pressure specialty gas systems. Shut off all upstream gas supply and depressurize the line completely before removing or installing the regulator. Verify that all fittings and connections meet applicable code requirements before returning the system to service. Do not exceed the rated inlet pressure of 550 psi.

Technical Specifications

• Pressure Rating: 550 psi
• Regulator Type: Single Stage, High Pressure
• Body Material: Brass Forged
• Diaphragm Material: Stainless Steel
• Certifications: UL Listed
• Length: 4.4 inches
• Width: 4.5 inches
• Height: 6.8 inches
• Weight: 4.05 pounds
• UPC: 716352382632

Standard Information

• Brand: VICTOR
• Manufacturer Part Number: 5645-8371
