Victor 0781-3600 Single Stage Oxygen Cylinder Regulator

Product Description

The VICTOR 0781-3600 is a heavy-duty, high-capacity, single-stage cylinder regulator engineered for industrial oxygen service. Part of the VICTOR EDGE Series 2.0 line, this second-generation regulator delivers consistent outlet pressure across a range of 2 to 60 psig and is built to perform in demanding fabrication, repair, and construction environments. Key design elements include a stainless steel diaphragm, a robust seat for optimum pressure and flow delivery, and fully enclosed modular gauges protected by metal gauge guards. A high-contrast, large-faced delivery gauge simplifies pressure setting in low-light or high-activity work areas. Licensed gas professionals and welding technicians are the primary installers and users of this regulator.

This regulator is suited for a wide range of industrial and trade applications where oxygen cylinder regulation is required. Typical use cases include automotive repair shops, light and heavy metal fabrication, civil construction sites, offshore oil operations, shipbuilding and barge work, railcar maintenance, and general repair and maintenance environments. Its high-capacity single-stage design supports operations that demand reliable, consistent gas flow from a standard oxygen cylinder valve connection.

Key Features

• Single-stage design with a 2 to 60 psig delivery pressure range for broad application coverage
• Extra-large 2.5-inch (63.5 mm) delivery gauge with high-contrast face for easy pressure reading
• Stainless steel diaphragm for durability in oxygen service
• Fully enclosed modular gauges with robust metal gauge guards for physical protection
• Color-coded, ergonomic SLAM knob design absorbs impact in the event of a cylinder fall
• High resistance to oxygen-related fires for added safety in industrial environments

Compatibility

Designed for use with standard industrial oxygen cylinders in single-stage cylinder regulator applications across automotive, fabrication, construction, and marine industries.

Installation Notes

Installation should be performed by a qualified welding or gas systems technician familiar with compressed gas cylinder equipment and applicable safety codes. Always close the cylinder valve and bleed all pressure from the regulator before connecting or disconnecting. Inspect the cylinder valve outlet for damage or debris before attaching the regulator, and ensure the connection fitting is fully seated and tightened without over-torquing. Oxygen regulators must never be exposed to oil, grease, or combustible contaminants, as contact can result in fire or explosion.

Technical Specifications

• Gas Type: Oxygen
• Stage Configuration: Single Stage
• Delivery Pressure Range: 2 to 60 psig
• Delivery Gauge Diameter: 2.5 inches (63.5 mm)
• Diaphragm Material: Stainless Steel
• Length: 5.4 inches
• Width: 5.7 inches
• Height: 5.3 inches
• Weight: 4.1 pounds
• UPC: 716352599566

Standard Information

• Brand: VICTOR
• Manufacturer Part Number: 0781-3600
