Victaulic V00478YBFF Koil-Kit Wye Strainer/Ball Valve Combination

Product Description

The VICTAULIC V00478YBFF Koil-Kit Wye Strainer/Ball Valve Combination, Series 78Y, features a 1/2 in FNPT x FNPT Union and a 400 psi pressure rating. Suitable for water media, it operates between -4 to 230 deg F. Constructed with a DZR brass alloy body, polished brass ball, and brass trim, it includes EPDM softgoods.

• Brass stem, EPDM O-ring/seal
• Provides simplified coil circuit installation that meets optimal hydronic system design requirements
• Full port

Product Highlights

The VICTAULIC Koil-Kit simplifies coil circuit installation and meets hydronic system design needs. It features durable brass alloy construction and EPDM seals.

Product Information

Standard Information

• Brand: VICTAULIC
• Manufacturer Part Number: V00478YBFF

Technical Specifications

• Actuator Type: Handle
• Ball Material: Polished Brass
• Body Material: DZR Brass Alloy
• End Style: FNPT x FNPT Union
• Media: Water
• Nominal Size: 1/2 In
• Port Type: Full
• Pressure Rating: 400 psi
• Series: 78Y
• Softgoods Material: EPDM
• Temperature Rating: -4 to 230 deg F
• Trim Material: Brass
• Connection Type: FNPT x FNPT
• Handle Material: Steel
• Material: Brass
• Operator Type: Lever
• Seal Material: EPDM
• Stem Material: Brass
• Seat Material: PTFE
