Victaulic V004786HBV Series 786H Hydronic Pressure Regulating Valve 1/2 in (VV004786HBV)

Product Description

Victaulic V004786HBV is a Series 786H hydronic pressure regulating and balancing valve with a 1/2 in solder connection and brass body, rated to 300 psi and -4°F (-20°C) to 250°F (120°C). The valve uses a Y-pattern globe design and a digital hand wheel (4 turns to open / 1440° rotation) with a memory stop for repeatable setpoints. Typical use cases include hydronic system balancing and flow regulation in heating and cooling circuits, flow 0.6–2.8 gpm.

• Brass Y-pattern globe balancing valve with 1/2 in solder end connections and calibrated handwheel
• Digital hand wheel operator with 4 turns to open (1440° rotation) and memory stop; polyamide/TPE handle and EPDM seal
• Rated pressure up to 300 psi; temperature range -4°F (-20°C) to 250°F (120°C); flow range 0.6 to 2.8 gpm

Product Highlights

1/2 in solder hydronic balancing valve; brass body; digital calibrated handwheel; 300 psi / -4°F to 250°F rating.

Product Information

Standard Information

• Brand: VICTAULIC
• Manufacturer Part Number: V004786HBV
