Victaulic LD44750PE0 Coupling Flexible 4 x 3 Inch Ductile Iron 750

Product Description

The VICTAULIC LD44750PE0 is a flexible coupling, 4 x 3 inch, made of ductile iron, 750 series, with E gasket. It is designed for connecting pipes, valves, and fittings. This coupling eliminates the need for two couplings and a reducing fitting, permitting direct reduction on piping runs.

• Flexible coupling design
• Ductile iron construction for durability
• E Gasket for secure sealing
• Suitable for connecting pipes, valves, and fittings

Product Highlights

This Victaulic coupling joins OGS roll grooved and cut grooved pipe, as well as OGS grooved fittings, valves and accessories.

Product Information

Standard Information

• Brand: VICTAULIC
• Manufacturer Part Number: LD44750PE0

Technical Specifications

• Brand: Victaulic
• Product Type: Flexible
• Size: 4x3IN
• Material: Ductile Iron
• Part Number: 750
• Finish: Orange Enamel
• Temperature Rating: -30 to 230 deg F
• Standard: ASTM A-536
• Bolt Size: 5/8x3-1/4IN
• Gasket Type: E
• Gasket Color: Green Stripe
• Gasket Material: EPDM
• Application: Connecting Pipes, Valves, and Fittings
• MPN: LD44750PE0
• Connection Size: 4 x 3 in
• Item Name: Grooved Reducing Coupling with Grade "E" EPDM Gasket
• Material Specifications: ASTM A536, Grade 65-45-12
• Maximum End Load: 4810 lb
• Model: 750
• Pressure Rating: 500 psi
• End Style: Grooved
• Fitting/Connector Type: Reducing Coupling
• Nominal Size: 4 x 3 In
• Series: 750
• Standards and Approvals: cULus Listed, Ductile Iron Conforming to ASTM A536, Grade 65-45-12, FM Approved, LPCB 104-1a/05, Vds Approved
