Victaulic L080107GEN QuickVic 107N 8 in Hot Dipped Galvanized Grooved Coupling

Product Description

The Victaulic L080107GEN is a QuickVic 107N coupling designed for use with carbon steel and stainless steel pipes. This product features hot dipped galvanized finishes for increased durability. It accommodates pressures up to 750 psi and a temperature range from minus thirty to two hundred fifty degrees Fahrenheit.

• Connects with carbon steel and/or stainless steel pipes.
• Pressures up to 750 psi.
• Temperature rating ranges from -30 to 250 degrees Fahrenheit.

Product Highlights

This QuickVic coupling provides effective sealing for pipe joints while restricting axial or angular movement.

Product Information

Standard Information

• Brand: Victaulic
• Material: Ductile Iron

Technical Specifications

• MPN: L080107GEN
• Connection Size: 8 inches
• Outside Diameter: 8-5/8 inches
• Pressure Rating: 750 psi
• Temperature Rating: -30 to 250 degrees Fahrenheit
• Length: 14-1/4 inches
• Material Specifications: ASTM A536, Grade 65-45-12
• Standards/Certifications: cULus listed, FM, LPCB, VDS approved, ASME B31.1, B31.9
