Victaulic FB64652C00 FireLock Style 652 2 x 1-1/4 in. Grooved Copper Concentric Reducer

Product Description

The Victaulic FireLock Style 652 with MPN FB64652C00 is a concentric reducer. This fitting facilitates a change in pipe size from two inches to one and one-quarter inches in copper piping systems. It is designed to connect different diameter pipes efficiently.

• Constructed from high-quality wrought copper.
• Compatible with style 607 rigid, style 606 rigid couplings, and style 641 flange adapters.
• Pressure rated up to three hundred psi.

Product Highlights

This fitting supports full-flow in copper systems making it effective for plumbing applications.

Product Information

Standard Information

• Brand: Victaulic
• MPN: FB64652C00

Technical Specifications

• Nominal Size: 2 x 1-1/4 inches
• Connection Type: Grooved x Cup
• Material: Wrought Copper
• Standards: ASTM B75, ASTM B152, UL, ULC Listed, FM Approved
• Maximum Pressure: 300 psi
• Outside Diameter: 2-1/8 x 1-3/8 inches
• Length: 3 inches
• Other Dimension: 0.97 inches cup
