Product Description
The Victaulic F020012P00 is a ductile iron elbow designed to connect pipes and facilitate directional changes. The product features a grooved connection type suitable for 2 inch pipes. It provides a 22-1/2 degree angle, making it ideal for various piping layouts.
- Connects pipe, provides change in direction and adapts sizes or components
- Supplied with Victaulic OGS grooves
- Pressure ratings conform to the ratings of Victaulic Style 177N couplings
Product Highlights
This elbow is designed for use with Victaulic couplings, valves, accessories, and pipe with Victaulic OGS groove profiles, ensuring secure and efficient connections.
Product Information
Standard Information
-
Brand: Victaulic
-
Material: Ductile Iron
Technical Specifications
-
Angle: 22-1/2 deg
-
Connection Size: 2 in
-
Connection Type: Grooved
-
Finish: Orange Enamel
-
Item Name: Elbow
-
Material Specifications: ASTM A536, Grade 65-45-12
-
Model: 12
-
Pressure Rating: 1000 psi
-
Standards/Certifications: ANSI/NSF 61 and 372, LPCB certified, UL listed, FM approved
