Victaulic CC0392NPE1 Mechanical-T Coupling with 1-1/2 in Grooved Bolted Branch Outlet

Product Description

The Victaulic CC0392NPE1 is a mechanical-T coupling designed for fire protection applications. It features a one-and-a-half inch grooved bolted branch outlet. The unit is constructed from ductile iron with an orange enamel finish, making it durable and reliable. This mechanical-T outlet allows for a direct branch connection in any pipe where a hole can be cut.

• Direct branch connection at any cut-in location
• Pressure responsive gasket seals around the pipe
• Gasket made from Grade E EPDM

Product Highlights

The 920N model from Victaulic accommodates both grooved and female threaded outlets, giving flexibility for various installations. It is supplied with plated bolts and is available in galvanized housing options.

Product Information

Standard Information

• Brand: Victaulic
• Part Number: VI920N.212.112G

Technical Specifications

• Connection Size: 2-1/2 x 1-1/2 in
• Finish: Orange Enamel
• Hole Diameter: 2 in
• Item Name: Mechanical-T Coupling with 1-1/2 in Grooved Bolted Branch Outlet and Grade E EPDM Gasket
• Length: 6.26 in
• Material: Ductile Iron
• Pressure Rating: 500 psi
• Temperature Rating: -30 to 230 deg F
• Material Specifications: ASTM A536, Grade 65-45-12
• Standards/Certifications: UL, ULC listed, FM, LPCB approved, VNIPO
