Victaulic CB60922YE0 FireLock Style 922 2 x 2 x 1 in Mechanical Joint x Mechanical Joint x FPT

Product Description

The Victaulic CB60922YE0 is a FireLock Style 922 mechanical joint fitting. This fitting is crafted from ductile iron and features a black enamel finish. It provides a solid connection for fire protection systems with a branch outlet.

• Connection Size: two inches x one inch
• Pressure Rating: three hundred psi
• Material: Ductile Iron

Product Highlights

The FireLock Style 922 is designed to connect directly to the pipe, providing a reliable branch connection at any cut location.

Product Information

Standard Information

• Brand: Victaulic
• MPN: CB60922YE0

Technical Specifications

• Item Name: Grooved Outlet Tee with one inch FPT branch outlet and Grade E EPDM Type-A gasket
• Finish: Orange Enamel
• Material Specifications: ASTM A536, Grade 65-45-12
• Model: 922
• Length: four point six inches
• Outside Diameter: two and three eighths x one point three one five inches
• Pressure Rating: three hundred psi
• Sub Brand: FireLock
