Victaulic C040924PE0 Strapless Thermometer Outlet 1-1/4 in FNPT

Product Description

The Victaulic Style 924 Vic-O-Well outlet offers a straightforward way to connect, combining thermowell features with a strapless mechanical outlet. The main body is crafted with integral lugs that fit into a hole in the pipe, ensuring a secure grip on the interior surface. A nut on the main body tightens to press the gasket and collar against the pipe's exterior, creating a solid joint. This outlet is machined to standard thread well dimensions, suited for industrial glass thermometers with a nominal bulb length of six inches. The slim design minimizes friction losses while providing an insertion length of three inches into the fluid. It accommodates two and a half inches for insulation and lagging, capable of withstanding a working pressure of three hundred psi on steel pipe.

• Fitting type: Outlet
• Material: Ductile Iron
• Pressure rating: 300 psi

Product Highlights

This outlet is designed for rugged environments and is ideal for various industrial applications.

Product Information

Standard Information

• Manufacturer: Victaulic
• Brand: Victaulic

Technical Specifications

• Dimensions: 7.09 in H
• End Style: FNPT
• Finish: Orange Enamel
• Length: 3.09 in W
• Material: Ductile Iron
• Nominal Size: 1-1/4 in
• Pressure Rating: 300 psi
• Schedule Rating: SCH 10
• Series: 924
