Vickers by Danfoss 02-137381-Z Vickers Fixed Displacement Double Vane Pump

Product Description

The Vickers by Danfoss 02-137381-Z is a fixed displacement double vane pump designed for efficiently transferring fluids. This pump is suitable for various applications requiring reliable hydraulic performance.

• Greater installation flexibility
• High operating pressure capabilities
• Low noise operation

Product Highlights

The Vickers fixed displacement pump ensures that your hydraulic system operates efficiently with minimal noise. It allows for adjustments in pump rotation, port orientation, and includes a cartridge kit that can be changed in the field.

Product Information

Standard Information

• Brand: Vickers by Danfoss
• Model Number: 4520V50E11-1DC22L

Technical Specifications

• Weight: 95.0 LB
• Mounting: Flange Mount
• Rotation: Left Hand (CCW)
• Port Type: Flange
• Port Size: 3 1/2
• Shaft Diameter: 1.25 in
• Shaft Length: 2.4375 in
• Shaft Type: Straight w/ Key
• Shaft Seal Type: Single Shaft Seal
• Seal Material: Buna-N
• Pressure Port Size, Cover End: 3/4 in Code 61
• Pressure Port Size, Shaft End: 1 1/2 in Code 61
• Displacement Shaft End (cu in/revolution): 9.9
• Displacement Cover End (cu in/revolution): 2.2
• Cover End Flow @ RPM: 11 gal/min @ 1200 rpm, 16.5 gal/min @ 1800 rpm
• Shaft End Flow @ RPM: 50 gal/min @ 1200 rpm, 75 gal/min @ 1800 rpm
• Manufacturer Part No.: 4520V50E11-1DC22L
