Vertical Cable 077-2010/05BK Cat6A Slim Patch Cable 0.5ft

Product Description

The VERTICAL CABLE 077-2010/05BK is a CAT6A slim type patch cord featuring a mold-injection snagless design and a PVC jacket. It utilizes 28AWG stranded bare copper conductors and unshielded RJ45 modular plugs with gold-plated pins, compliant with 568B wiring. Supports PoE+ (Type 2) and is UL-listed. Ideal for high-speed data transmission up to 10 Gbps in various networking applications.

• Mold-injection snagless design
• 28AWG stranded conductors
• Bare copper conductors
• Supports PoE+ (Type 2)
• Slim and flexible design for easy installation

Product Highlights

High-performance CAT6A slim patch cable with snagless design, ideal for demanding networking environments.

Product Information

Standard Information

• Brand: VERTICAL CABLE
• Manufacturer Part Number: 077-2010/05BK

Technical Specifications

• Category: CAT6A
• Speed: Up to 10 Gbps
• Bandwidth: 500 MHz
• Jacket Material: PVC
• Connector Type: RJ45
• Conductors: Bare Copper Stranded
• Plugs: Unshielded RJ45 Modular
• Pins: 8P8C Gold Plated
• Wiring Color Code: 568B
• Compliance: RoHS Compliant, UL
• Diameter: 3.8mm (Slim Type)
• type: Mold-Injection-Snagless, Slim Booted
• series: 077
• voltage rating: 300 V
• Conductor Size: Stranded 28 AWG
• Conductor Material: bare copper
• Insulation Material: high-density polyethylene (HDPE)
• Jacket Diameter: 0.15 in. (3.8 mm)
• Plugs Type: 8P8C modular plugs (RJ45)
• Plugs Housing: Flame-retardant polycarbonate (PC) 94V-0
• Plugs Contacts: 50-µin gold plated
• Cable Length: 0.5 ft
