Veris Industries V221 Enclosed Relay 24 VAC/DC 208-277 VAC

Product Description

The Veris Industries V221 is an enclosed relay designed for dependable performance in building automation systems. This relay operates on 24 VAC/DC and is suitable for voltages ranging from 208 to 277 VAC. It supports SPST switching with capabilities of handling a maximum current of twenty amps at two hundred forty volts AC and eight amps at twenty-eight volts DC. The relay features an HOA switch and an LED indicator for improved visibility and control.

• Relay Type: SPST
• Voltage Compatibility: 24 VAC/DC, 208-277 VAC
• Rated Current: 20A @ 240VAC, 8A @ 28VDC

Product Highlights

This relay fits well in applications requiring precise control and reliable functionality in harsh environments.

Product Information

Standard Information

• Brand: Veris Industries
• Product Type: Relay

Technical Specifications

• MPN: V221
• Dimensions: Four inches long x two point zero four inches wide x two point five inches high
• Maximum Switching Current: 12 A, 14 V DC; 20 A, 240 V AC; 8 A, 28 V DC
• Relay Coil Voltage: 208-277 V AC, 24 V AC, 24 V DC
• Ambient Air Temperature for Operation: -40 to 55 °C
• Certification: UL
• Mounting Support: DIN rail, wall
