Veris Industries U013-0013 BACnet Router Access Communication Gateway

Product Description

The Veris Industries BACnet router, MPN U013-0013, allows access to all Veris BACnet MS/TP products over a network using the BACnet IP protocol.

• Supports downstream 2-wire BACnet MS/TP RS-485 communication
• Offers a downstream baud rate range from 9600 to 78,600
• Includes upstream Ethernet with a fixed IP on 10/100 Mb

Product Highlights

Product Information

Standard Information

• Brand: Veris Industries
• Manufacturer: Schneider Electric

Technical Specifications

• Supply Voltage: 24VDC +/- 10% or 24VAC +/- 10%
• Power Consumption: 2W or 4VA at 47 to 63 Hz
• Operating Temperature: 0 degrees C to 60 degrees C (32 degrees F to 140 degrees F)
• Downstream Baud Rate: 9600 to 78,600
• Communication Type: BACnet MS/TP RS-485
• Upstream Type: 10/100 Mb Ethernet, Fixed IP
