Veris H722LC LV Instrument Current Transformer 0-5 VDC 0-10/20/40A

Product Description

The Veris H722LC offers reliable current sensing for industrial applications, designed to precisely measure currents ranging from 0-10, 20, or 40 amperes. Ideal for controlling motor loads and monitoring power usage, the model provides a solid-core housing for durability.

• Proportional 0-5VDC output for load trending.
• Switch-selectable range setting simplifies field adjustments.
• Self-powered operation and solid-core design enhance installation simplicity.

Product Highlights

This compact current sensor employs hall-effect technology for non-contact current measurement, ensuring minimal mechanical wear and long-term accuracy. It is encapsulated within a UL-listed and CE compliant solid-core housing, making it suitable for various industrial environments.

Product Information

Standard Information

• Brand: Veris
• MPN: H722LC
• Insulation Class: 600VAC RMS (UL), 300VAC RMS (CE)

Technical Specifications

• Current Range: 0-10/20/40 Amperes
• Output Voltage: 0-5 VDC
• Temperature Range: -15 to 60 degrees Celsius (5 to 140 degrees Fahrenheit)
• Humidity Range: 10-90% RH non-condensing
• Accuracy: ±1%
• Response Time: Less than 1 ms
• Agency Approvals: UL, CE
