Veris Industries EP3030S2 Differential Air Pressure Transducer 3...15 psi (0.2...1 bar) 4.3 mm

Product Description

The Veris Industries EP3030S2 is a differential air pressure transducer designed for monitoring air ducts, filters, and fans. This device is useful in various applications including HVAC systems and pneumatic controls. The transducer has a pressure measurement range of three to fifteen psi and can work with dry air and inert gases.

• Measurement accuracy of +/- 1 % FS
• Compatible with pneumatic actuators and dampers
• Local signaling with red/green LED

Product Highlights

This transducer features robust construction suitable for plant rooms. It is designed for easy installation with a three-wire setup and offers multiple output types.

Product Information

Standard Information

• Brand: Veris Industries
• MPN: EP3030S2

Technical Specifications

• Pressure Measurement Range: 3...15 psi (0.2...1 bar), 0...20 psi (0...1.35 bar)
• Ambient Air Temperature for Operation: 5-60 °C
• Relative Humidity: 10-90 % RH, non-condensing
• Fitting Size: 4.3 mm (0.18)
• Wiring Technique: 3-wire
• Output Type: 4...20 mA, 0...10 V DC
• Standards: EN 61000-6-1
• Device Application: Pneumatic actuated dampers, pneumatic actuators
