Veris Industries BGR-FC5-BM-P1-FA6A-P Programmable BTU Monitor BACnet/Modbus Panel

Product Description

The Veris Industries Programmable BTU Monitor, model BGR-FC5-BM-P1-FA6A-P, is designed for monitoring flow and BTU. This unit supports a variety of communication protocols including Modbus and BACnet, making it suitable for integration in energy management systems.

• Application: Flow and BTU monitoring
• Communication: EIA-485 (RS-485), Modbus, BACnet, USB
• Display Type: 128 by 64 pixel LCD graphical display with LED backlight

Product Highlights

This BTU Monitor is compact and can be mounted on a panel. It operates effectively in a wide range of conditions.

Product Information

Standard Information

• Brand: Veris Industries
• Manufacturer: Schneider Electric

Technical Specifications

• Operating Humidity: 0 to 85%, non-condensing
• Operating Temperature: 32 to 130 °F (0 to 55 °C)
• Output Frequency Range: TTL, 1 to 4000 Hz, square wave; Uncertainty: ±0.01% reading; Resolution: 0.01 Hz
• Power Consumption: 8 W (minimum power supply required)
• Relay Configuration: One Form C mechanical relay and one Form A solid state relay
• Relay Contact Ratings: Form C Relay: 5A (N.C. or N.O.), 5 to 24 Vdc; Form A Relay: 1A, 60V
• Standards: CE, UL 61010-1 and ANSI/ISA- 61010-1
• Supply Voltage AC Range: 9 to 28 Vac RMS (50 to 60 Hz)
• Supply Voltage DC Range: 10 to 40 Vdc
• Totalizer Resetable: Yes
