Product Description
The Veris Industries BGR-DR-G-RZ-R-S-AKWWCAKNXXTGRF is a flow meter designed for precise flow and energy monitoring. This device operates on a voltage range of one hundred ten to two hundred twenty volts and is suitable for pipes measuring two to twenty-four inches in diameter. It features a keypad for easy navigation and offers communication protocols including BACnet and Modbus, making it versatile for various applications.
- Application: Measures flow and energy.
- Type: Ultrasonic sensor with high accuracy.
- Operating temperature: From negative four to one hundred forty degrees Fahrenheit.
Product Highlights
This flow meter is ideal for monitoring a variety of mediums, such as water, sewage, and glycol. Its graphical display allows for clear readings, and it includes two transducers for effective measurement in various conditions.
Product Information
Standard Information
-
Brand: Veris Industries
-
Model: BGR-DR-G-RZ-R-S-AKWWCAKNXXTGRF
Technical Specifications
-
Input Power: Eighty-five to two hundred sixty-four volts AC
-
Measurement Range: One to twenty feet per second
-
Accuracy: Plus or minus 0.5% of reading
-
Resolution: 128 x 64 pixel LED display
-
Pipe Material: Compatible with copper, polymer, steel, and stainless steel
-
Operating Fluid Temperature: Fourteen to one hundred fifty degrees Fahrenheit
-
Fitting Size: Two to twenty-four inches
-
Outputs: 4-20mA and frequency output
