Veris Industries BGR-DR-G-CH-R-S-AKWWCAKNXXTGRF Flow Meter BTU 3/4 In Copper Pipe 110-220V

Product Description

The Veris Industries Flow Meter, model BGR-DR-G-CH-R-S-AKWWCAKNXXTGRF, is designed for flow and energy monitoring in various applications. This flow meter is compatible with three-quarter inch copper pipes and operates on a voltage range of one hundred ten to two hundred twenty volts. It includes a keypad for easy navigation and is equipped with fifty-foot cables for flexible installation.

• Application: Flow and Energy Monitoring
• Communication Protocol: BACnet and Modbus support
• Flow Measurement Accuracy: ±0.5%

Product Highlights

This flow meter measures both flow rate and BTU, providing accurate and reliable data for monitoring water delivery, sewage, and cooling processes.

Product Information

Standard Information

• Brand: Veris Industries
• Model Number: BGR-DR-G-CH-R-S-AKWWCAKNXXTGRF

Technical Specifications

• Input Power: Eighty-five to two hundred sixty-four volts AC
• Flow Measurement Range: One to twenty feet per second
• Operating Temperature: Negative four to one hundred forty degrees Fahrenheit
• Housing Material: Aluminum with EPDM gasket, rated NEMA Type 4X
• Display: LED backlit graphical display, adjustable brightness
• Communication Ports: EIA-485 Modbus RTU and BACnet MS/TP
• Flow Sensor Type: Ultrasonic
