Veris Industries BGR-DQ-G-RZ-R-S-AK-WW-N-XX-TGF Flow Meter 110-220V (2+ In Pipe)

Product Description

The Veris Industries BGR-DQ-G-RZ-R-S-AK-WW-N-XX-TGF Flow Meter is designed for measuring flow in pipes sized two to twenty-four inches. This ultrasonic flow meter operates at a voltage range of one hundred ten to two hundred twenty volts and comes equipped with a keypad and extensive cable coverage. Key features include:

• Flow measurement with ± 0.5% accuracy
• Integrated display with adjustable settings and a user-friendly interface
• Compatible with various media such as water, sewage, and chemicals

Product Highlights

The BGR-DQ-G-RZ-R-S-AK-WW-N-XX-TGF Flow Meter is suitable for HVAC systems, plumbing applications, and industrial processes requiring precise flow measurement. With its robust aluminum housing and NEMA Type 4X protection, it is built for durability in various environments.

Product Information

Standard Information

• Brand: Veris Industries
• Manufacturer: Schneider Electric
• Model Number: BGR-DQ-G-RZ-R-S-AK-WW-N-XX-TGF

Technical Specifications

• Fitting Size: 2-24 inches
• Input Power: 85 to 264V AC, 47 to 63 Hz
• Outputs: 4 to 20 mA, Frequency Output, Pulse
• Operating Temperature: -4 to 140 °F (-20 to 60 °C)
• Flow Measurement Range: 1 - 20 ft/s (0.3 - 6 m/s)
• Transducers: 2 included with 50 ft cables
• Flow Sensor Type: Ultrasonic
• Housing: Aluminum with EPDM gasket
