Veris BGR-8380210000-1202 BTU System Hot and Cold Service 1 In Tee NPT Modbus BACNet Outputs

Product Description

The Veris BGR-8380210000-1202 is a BTU system designed for both hot and cold services. This system includes a one-inch NPT tee fitting and supports pulse output along with Modbus and BACnet communication protocols.

• Application: Flow and BTU determination
• Communication: ModBus (RTU), BACnet (MS/TP)
• Flow Measurement Accuracy: ±2%

Product Highlights

This sensor is ideal for monitoring and controlling energy consumption in heating and cooling systems. It is equipped with a brass and polymer fitting construction, ensuring durability and reliability across various installations.

Product Information

Standard Information

• Brand: Veris Industries
• Manufacturer: Schneider Electric

Technical Specifications

• Fitting Size: 1 In NPT
• Flow Measurement Range: 2.7 - 40.5 GPM (10 - 153 LPM)
• Operating Temperature: 20 - 260 °F (-6.7 - 126.7 °C)
• Measurement Type: BTU
• Pipe Material: Copper, Polymer, Steel, Stainless Steel
• Temperature Measurement Range: 0 - 260 °F (-6.7 - 126.7 °C)
• Totalizer Resettable: No
