Venti SC5-36MM44 Flexible Yellow Coated Gas Connector MIP x MIP 36 in

Product Description

The Venti SC5-36MM44 is a flexible yellow coated gas connector designed for secure connections between gas appliances and piping systems. Its length of thirty-six inches makes it suitable for both indoor and outdoor use.

• Hose material is 304L stainless steel for durability.
• Compatible with various gas types including natural, manufactured, and liquefied petroleum gases.
• Resistant to harsh chemicals and UV rays due to ProCoat technology.

Product Highlights

Ideal for large demand appliances, this gas connector provides a reliable solution for heating and cooking needs.

Product Information

Standard Information

• Connection Size: 1/2 in. x 1/2 in.
• Hose Length: 36 in.

Technical Specifications

• BTU Capacity: 125000 BtuH
• Hose Inside Diameter: 1/2 in.
• Hose Outside Diameter: 5/8 in.
• Max Working Pressure: 1/2 psi
• Maximum Temperature: 150 Degree F
• Temperature Range: -40 Degree to 150 Degree F
• Standards: ANSI Z21.24/Z21.75/CSA 6.10/6.27
• Country of Origin: Made in USA
