VELAN Velan F03-00313-SSEAE Flgd Unibody Live Loaded Ball Valve W/Oval Handle 1/2 IN
VELAN Velan F03-00313-SSEAE Flgd Unibody Live Loaded Ball Valve W/Oval Handle 1/2 IN

Velan F03-00313-SSEAE Flgd Unibody Live Loaded Ball Valve W/Oval Handle 1/2 IN

Brand: VELAN
SKU: F03-00313-SSEAE-H
Availability: In Stock

Ships same day if ordered by 12 pm
$367.18
$367.18
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Velan F03-00313-SSEAE is a flanged unibody live loaded ball valve with an oval handle. This Memoryseal™ Class 150 ball valve features a regular port and is constructed from 316 stainless steel. It is designed for a wide range of applications. The valve has a 1/2 IN nominal size.

  • Designed with 3-way packing arrangements for superior stem sealing.
  • Meets NACE specifications for demanding environments.
  • Compliant with API 608 and dual qualified to API 641 and ISO 15848-1 fugitive emissions standards.

Product Highlights

The Velan Memoryseal™ ball valve offers robust construction and reliable performance for various industrial applications, ensuring tight sealing and longevity.

Product Information

Standard Information

  • Brand: VELAN
  • Manufacturer Part Number: F03-00313-SSEAE-H
Technical Specifications
Sub Brand
Memoryseal™
Item Name
Ball Valve
Type
Regular Port, Live Loaded, Uni-Body, Standard
Nominal Size
1/2 IN
Connection Type
Flanged
Pressure Class
Class 150
Temperature Rating
100 - 450 DEG F
Body Material
316 Stainless Steel
Operator Type
Oval Handle
Handle Material
304 Stainless Steel
Stem Material
316 Stainless Steel
Trim Material
316 Stainless Steel
Packing Material
PTFE/Graphite
Gland Material
304 Stainless Steel
Seat Material
MPTFE
Seal Material
MPTFE
Material Standard
Body: ASTM A351 Grade CF8M, Stem And Gland: ASTM A276
Material Specification
Ball: 316 Stainless Steel
Industry Standards
ASME B16.34, BS 5351, API 608, ISO 5211, API 607 rev 5/ISO 10497
Width
4-1/4 IN
Lead Free
No
Other Physical Dimension
3.45 IN Inlet Center To Top Of Handle, 5.9 IN Handle Length
Additional Specifications
Flow Co-Efficient (Cv): 9
Brand
Velan
Firesafe
No
Manufacturer
Velan Valve Corporation
