Valve S1 VRC S1 Limit Switch

Product Description

The VALVE S1 is a limit switch. It is also a pressure excess valve with sizes from DN15 to DN150 and connections for flanges (EN, ANSI) and threaded (BSP, NPT). Suitable for liquids, gases, and steam, with body material GGG40.3 / WCB / CF3M.

• Standard on most Newport pneumatic isolators
• Repeatability of ±0.010 in. (0.25 mm)
• Includes pressure gauge

Product Highlights

This valve offers a compromise between isolation and re-leveling response time. It features nominal pressure PN25 – PN40 / CLASS 150 – 300 and inlet pressure max of 15 barg.

Product Information

Standard Information

• Brand: VALVE
• Manufacturer Part Number: S1
• Country of Origin: SPAIN

Technical Specifications

• Sizes: DN15 to DN150 (others consult)
• Connection: Flanges (EN, ANSI) and Threaded (BSP, NPT)
• Fluids: Liquids, gases and steam
• Body material: GGG40.3 / WCB / CF3M
• Nominal pressure: PN25 – PN40 / CLASS 150 – 300
• Inlet pressure max.: 15 barg
• Range: 0,1 – 15 barg
• Kvs value: Up to 240 m3/h
• Type: Leveling Valve
• Pressure Gauge: Yes
