Value Collection TXSSN200 2-way Ball Valve 2 in Full Port

Product Description

The VALUE COLLECTION TXSSN200 is a two-way manual ball valve designed for full-port flow control in piping systems that demand reliable shutoff and minimal pressure drop. Built with a 304 stainless steel body and lead-free brass trim, this valve handles steam service up to 150 psi. The lever handle gives technicians fast quarter-turn operation, making it a practical choice for isolation duty in mechanical rooms, process lines, and HVAC hydronic systems. Plumbers, pipefitters, and mechanical contractors are the primary installers. The FNPT x FNPT end connections thread directly into standard pipe without additional adapters.

This valve suits residential and light commercial plumbing, HVAC hydronic piping, steam distribution, and general industrial fluid service where a full-port two-way shutoff is required. The full-port design maintains the same internal diameter as the connecting pipe, reducing turbulence and flow restriction. At 2 inches pipe size with NPT threading per ANSI B1.20.1, it fits into common iron and steel piping assemblies. Its lead-free construction makes it suitable for potable water applications where lead-free compliance is required by local code.

Key Features

• 304 stainless steel body resists corrosion in wet and steam service environments
• Full-port design maintains full pipe bore for unrestricted flow
• 150 psi steam pressure rating supports demanding mechanical system applications
• PTFE seat and seal material provides chemical resistance and low-friction operation
• Lead-free construction meets potable water installation requirements
• Quarter-turn lever handle allows fast visual confirmation of open or closed position
• FNPT x FNPT end connections per ANSI B1.20.1 for straightforward threaded installation

Compatibility

Designed as a standard 2-inch FNPT full-port ball valve for use in threaded piping systems in plumbing, hydronic HVAC, steam, and general fluid service applications where 304 stainless steel body material and lead-free construction are specified.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and ASME standards. Shut off system pressure and drain the line before removing or installing any valve. Use thread sealant or PTFE tape rated for the service fluid and temperature on all NPT connections. Do not exceed the rated steam or fluid pressure for this valve as marked by the manufacturer.
