Value Collection TXSSN150 Ball Valve 1-1/2 in Full Port Fnpt

Product Description

The VALUE COLLECTION TXSSN150 is a 2-way manual ball valve designed for full-port flow control in plumbing, HVAC, and industrial piping systems. Built with a 304 stainless steel body and lead-free brass trim, this valve handles demanding service conditions where corrosion resistance matters. The full-port design minimizes pressure drop across the valve, keeping flow unrestricted through 1-1/2 inch piping. PTFE seats and seals provide reliable shutoff with low operating torque. The lever handle allows for quick quarter-turn open and close operation. Licensed plumbers, pipefitters, and HVAC technicians install this valve in both commercial and residential applications.

This valve is suited for water, gas, and compatible fluid service in residential and light commercial installations. The FNPT x FNPT end connections thread directly into standard NPT-threaded piping systems. The 1-1/2 inch pipe size fits common main branch and secondary distribution lines. Its compliance with ANSI, ASME, FM, and UL standards makes it appropriate for gas and potable water service where certified components are required by code or inspection.

Key Features

• 304 stainless steel body for corrosion resistance in wet and gas service environments
• Full-port design minimizes flow restriction and pressure drop
• Lead-free construction meets potable water and plumbing code requirements
• PTFE seats and seals for low-friction, dependable shutoff
• FNPT x FNPT connections compatible with standard NPT threaded pipe
• Quarter-turn lever handle for fast manual actuation
• Certified to ANSI B1.20.1, ASME B16.44, FM 1140, UL 125, UL 842, and CGA standards

Compatibility

Designed as an OEM-style replacement or new-install ball valve for 1-1/2 inch NPT threaded piping systems in plumbing, HVAC hydronic, and gas distribution applications where a full-port, lever-operated shutoff is required.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable IPC, IFGC, or local mechanical codes. Shut off supply pressure and depressurize the line before threading in the valve. Apply appropriate thread sealant compatible with the service fluid on all NPT connections. Do not over-torque threaded connections into the valve body, as this can stress the stainless steel ports.
