Value Collection TXSSN125 Ball Valve 1-1/4 in Full Port Fnpt

Product Description

The VALUE COLLECTION TXSSN125 is a 2-way manual ball valve designed for full-port flow control in plumbing, HVAC, and industrial piping systems. Built with a 304 stainless steel body and lead-free brass trim, this valve handles demanding service environments where corrosion resistance and regulatory compliance are required. The full-port design minimizes pressure drop across the valve, maintaining maximum flow capacity. A lever handle provides quick quarter-turn on/off operation. The PTFE seats and seals deliver a tight shutoff with low torque requirements. Licensed plumbers and pipefitters are the primary installers for this type of valve in commercial and residential applications.

This valve is suited for use in residential and commercial water supply, hydronic heating, cooling systems, and general fluid handling lines where a 1-1/4 inch FNPT connection is required. The full-port configuration makes it a practical choice for installations where maintaining pipe flow diameter is a priority, such as main supply branches, boiler connections, and chiller piping. The lead-free construction meets current potable water installation requirements in jurisdictions that enforce lead-free plumbing standards.

Key Features

• 304 stainless steel body for corrosion resistance in wet and chemically active environments
• Full-port design maintains full pipe bore to minimize pressure drop
• FNPT x FNPT end connections for standard threaded pipe installation
• PTFE seats and seals provide reliable shutoff and chemical resistance
• Lead-free brass trim meets potable water compliance requirements
• Lever handle allows fast quarter-turn operation and clear visual open/closed indication
• Meets multiple standards including ANSI B1.20.1, ASME B16.44, FM 1140, UL 125, and UL 842

Compatibility

Designed as an OEM-style replacement or new-installation valve for 1-1/4 inch threaded pipe systems requiring a full-port 2-way ball valve with FNPT x FNPT connections.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local codes and ASME B16.33 or ASME B16.44 standards. Shut off the water supply and depressurize the line before removing any existing valve or making new connections. Apply thread sealant or PTFE tape to male threads per local code requirements before making up the joint. Do not use the lever handle as leverage when tightening the valve body into the fitting.
