Value Collection R52000973 10-32 Pan Head Machine Screw

Product Description

The VALUE COLLECTION R52000973 is a 10-32 pan head machine screw designed for general-purpose fastening in metal assemblies, enclosures, and light structural applications. The slotted drive accepts a standard flat-blade screwdriver, and the pan head profile seats flush against flat mating surfaces without a washer. Made from steel with a zinc finish, this screw offers moderate corrosion resistance suitable for indoor and protected environments. The thread size is 10-32 (UNF), with a length under head of 3/8 inch. Manufactured to ASME B18.6.3 and SAE J82 standards, this fastener meets widely recognized dimensional and mechanical requirements for inch-series machine screws.

This screw is used across HVAC equipment assembly, electrical panel work, plumbing fixture mounting, and general sheet metal or light structural fastening. The 10-32 thread is a common size found in equipment enclosures, junction boxes, motor mounts, and control panels. It is sold in multiples of 100, making it practical for service trucks, shop stock, and production use. The zinc finish provides adequate protection for dry indoor installations and controlled environments where moisture exposure is minimal.

Key Features

• 10-32 UNF thread for compatibility with standard tapped holes in metal components
• 3/8 inch length under head for use in thin-gauge assemblies and panels
• Pan head profile distributes clamping load across a flat bearing surface
• Slotted drive works with common flat-blade screwdrivers and bits
• Steel construction with zinc finish for basic corrosion resistance in dry environments
• Meets ASME B18.6.3 and SAE J82 dimensional and mechanical standards

Compatibility

Designed as a standard inch-series machine screw for use in any application requiring a 10-32 UNF thread, pan head style, and 3/8 inch length under head in steel with zinc finish.

Installation Notes

Installation is performed by hand or with a flat-blade screwdriver or appropriate power driver bit. Ensure the mating hole is properly tapped to 10-32 UNF before driving the screw to avoid cross-threading. Do not overtighten in thin sheet metal, as the pan head may pull through or strip the thread. Power down electrical equipment and depressurize systems before accessing fastened enclosures or components.
