Value Collection R50000367 Concrete Anchor 5/8 in 6 in

Product Description

The VALUE COLLECTION R50000367 is a hammer drive concrete anchor used to fasten materials to concrete, masonry, and block surfaces. It is driven in place with a hammer and expands upon installation to create a secure mechanical hold. The anchor measures 5/8 inch in diameter and 6 inches in overall length, with a minimum embedment depth of 3-1/2 inches. Constructed from steel with a zinc-plated finish, it offers corrosion resistance suitable for dry interior and light-duty applications. The hex nut head allows for standard wrench removal or adjustment after installation. Licensed tradespeople and experienced contractors typically install this type of fastener on commercial and residential jobsites.

This anchor is suited for attaching structural supports, equipment mounts, conduit straps, pipe hangers, and similar fixtures to poured concrete or masonry substrates. It is commonly used by electricians, plumbers, HVAC technicians, and general contractors who need a fast, reliable anchoring method without the use of adhesives or pre-set inserts. The hammer-drive installation method makes it well suited for applications where speed and simplicity are priorities on active jobsites.

Key Features

• 5/8 inch diameter with 6 inch overall length for deep embedment capability
• Minimum embedment depth of 3-1/2 inches for secure holding strength
• Zinc-plated steel construction provides corrosion resistance in dry conditions
• Hex nut head style compatible with standard wrenches for easy installation and removal
• Hammer-drive installation requires no special tooling beyond a standard hammer and setting tool

Compatibility

Designed as an OEM-style replacement and general-use concrete anchor for use in poured concrete, masonry block, and brick substrates requiring a 5/8 inch diameter hammer drive fastener.

Installation Notes

Installation is performed by drilling a hole matching the anchor diameter, inserting the anchor to the required embedment depth, and driving the pin with a hammer to expand the anchor body. Power down or de-energize any nearby electrical systems before drilling into concrete surfaces that may contain embedded conduit or wiring. Follow applicable building codes and fastener manufacturer load ratings for the intended application. A licensed contractor or qualified tradesperson should verify anchor selection and spacing for structural or load-bearing installations.
