Value Collection R50000366 Concrete Anchor 3/8 in Zinc-plated

Product Description

The VALUE COLLECTION R50000366 is a hammer drive concrete anchor designed for fast, reliable fastening into concrete, block, and masonry substrates. Made from zinc-plated steel, it resists corrosion in typical interior and light exterior applications. The anchor measures 3/8 inches in diameter with an overall length of 1-7/8 inches and requires a minimum embedment of 1-1/4 inches for proper holding strength. Installation is straightforward: drill the correct hole diameter, insert the anchor, and drive the pin with a hammer to expand the body and lock it in place. This anchor is commonly used by electricians, plumbers, HVAC technicians, and general contractors who need a quick-set fastener when attaching brackets, strut channel, conduit supports, or pipe hangers to concrete surfaces.

This hammer drive anchor suits residential and light commercial applications where a flush or low-profile fastener is needed in concrete or masonry. It is well-suited for attaching electrical boxes, pipe straps, equipment mounting brackets, and similar hardware directly to poured concrete floors, walls, or block construction. The hex nut head style allows for standard wrench engagement after installation. A minimum order quantity of 50 units makes it practical for job-site supply and bulk fastener inventory.

Key Features

• 3/8 inch diameter provides substantial holding capacity in concrete and masonry
• Zinc-plated steel construction offers corrosion resistance for interior and light exterior use
• 1-1/4 inch minimum embedment depth ensures secure mechanical lock in the substrate
• Hex nut head style allows wrench tightening and secure clamping of attached hardware
• Hammer-drive installation requires no special tools beyond a standard drill and hammer
• 1-7/8 inch overall length suits thin-to-medium slab and block fastening applications

Compatibility

Designed as a standard hammer drive anchor for use in poured concrete, concrete block, and solid masonry. Verify base material hardness and hole diameter match anchor specifications before installation.

Installation Notes

Installation is performed by drilling a hole matching the anchor diameter to at least the minimum embedment depth, clearing debris from the hole, inserting the anchor, and striking the drive pin with a hammer until fully seated. Ensure the concrete or masonry substrate is sound and free of cracks at the fastening point. Follow applicable building codes and manufacturer load ratings when determining anchor spacing and edge distances for structural or load-bearing applications. Do not install in deteriorated, spalled, or wet concrete without verifying suitability.
