Value Collection PS-MH-HPC1-095 Hydraulic Female Elbow 3/8in

Product Description

The VALUE COLLECTION PS-MH-HPC1-095 is a steel hydraulic hose female elbow fitting rated for 10,000 psi service. It features a 3/8-inch NPTF (National Pipe Taper Fuel) thread and is designed for use in high-pressure hydraulic lines where a direction change is required at the hose connection point. The elbow geometry allows routing of hydraulic hose in confined or angled installations without stressing the hose end. This fitting is installed by hydraulic system technicians, millwrights, and heavy equipment mechanics working on industrial, agricultural, or construction equipment hydraulic circuits.

This female elbow fitting is suited for high-pressure hydraulic applications in both mobile and stationary equipment. It is appropriate for use in systems operating up to 10,000 psi and within a temperature range of -22 degrees F to 212 degrees F. The NPTF thread type provides a pressure-tight seal through thread interference, making it a common choice for hydraulic manifolds, cylinders, pumps, and control valve assemblies where a right-angle hose port is needed.

Key Features

• 10,000 psi maximum pressure rating for demanding hydraulic service
• 3/8-inch NPTF thread provides metal-to-metal sealing without a separate sealant in many applications
• Steel construction for strength and durability in high-pressure environments
• Female elbow configuration allows angled hose routing in tight installations
• Operating temperature range of -22 degrees F to 212 degrees F
• Compact profile: approximately 1.4 inches length by 1.02 inches width by 1.02 inches height

Compatibility

Designed as an OEM-style replacement or service fitting for high-pressure hydraulic hose assemblies using 3/8-inch NPTF female elbow connections rated to 10,000 psi.

Installation Notes

Installation should be performed by a qualified hydraulic technician or mechanic familiar with high-pressure fluid power systems. Depressurize and isolate the hydraulic circuit completely before removing or installing any fittings. NPTF threads rely on thread-form interference for sealing; inspect threads carefully before assembly and apply thread sealant per the system manufacturer's recommendation if required. Torque fitting to the system manufacturer's specification using calibrated hydraulic fitting wrenches.
