Value Collection PB1- Crimp Bullet Connector 22-16 Awg

Product Description

The VALUE COLLECTION PB1- is a crimp-style bullet connector designed for splicing and terminating 22 to 16 AWG copper wire. The connector features a nylon insulation sleeve in a natural color and a copper contact with a bullet diameter of 0.236 inches (6 mm) and an overall length of 0.598 inches. It is installed using a standard crimping tool and is suited for low-voltage wiring connections in automotive, HVAC control circuits, appliance wiring, and general electrical assembly work. This connector meets UL and cUL listing requirements and is RoHS compliant.

This bullet connector is appropriate for residential and light commercial wiring applications where a reliable crimp termination is needed on 22 to 16 AWG conductors. Common installation scenarios include control wiring splices, harness repairs, and field terminations in HVAC equipment, motor wiring, and appliance service. The nylon insulation provides basic mechanical protection at the termination point. These connectors are sold in minimum order quantities of 25 units.

Key Features

• Accepts 22 to 16 AWG wire for a wide range of control and power wiring applications
• Copper contact material provides solid electrical conductivity
• Nylon insulation sleeve in natural color for standard identification
• 0.236-inch (6 mm) bullet diameter fits common bullet receptacles
• UL Listed, cUL Listed, and RoHS compliant for code-compliance assurance
• Crimp termination — no soldering required

Compatibility

Designed as a standard crimp bullet connector compatible with 22 to 16 AWG copper wire terminations where a 0.236-inch bullet diameter receptacle is required.

Installation Notes

Installation is performed by electricians or HVAC technicians using a ratcheting or standard crimping tool sized for the appropriate AWG range. De-energize all circuits before making or breaking any wire terminations. Strip wire to the manufacturer-recommended length before inserting into the connector barrel and crimping. Verify crimp integrity with a pull test before restoring power.
