Value Collection P20172 Clevis Pin 5/8 in Stainless Steel

Product Description

The VALUE COLLECTION P20172 is a standard clevis pin machined from 18-8 stainless steel and designed for use in clevis and cotter pin assemblies across a wide range of mechanical and structural applications. The pin measures 5/8 inch in diameter and 1-1/2 inches overall length, with a usable length of 1-11/32 inches and a cross-hole diameter of 5/32 inch sized to accept a standard cotter pin or hitch pin clip. The uncoated stainless steel finish provides corrosion resistance without surface treatments that can add dimensional variability. This hardware is installed by maintenance technicians, millwrights, HVAC mechanics, and plumbing or mechanical contractors wherever a removable pivot or linkage fastener is required.

The P20172 clevis pin is suited for light-duty to medium-duty pivot and linkage connections in residential and commercial mechanical systems. Common applications include HVAC damper linkages, valve actuator connections, pump mounting brackets, and general mechanical assemblies where a removable pin fastener is needed. The compact overall length makes it appropriate for tight installation spaces. Each unit is sold individually.

Key Features

• 18-8 stainless steel construction provides corrosion resistance in wet or outdoor service environments
• 5/8 inch pin diameter for standard clevis fitment
• 1-11/32 inch usable length accommodates standard clevis jaw widths
• 5/32 inch cross-hole accepts standard cotter pins or hitch pin clips for positive retention
• Uncoated finish maintains consistent dimensional tolerances

Compatibility

Designed as a standard-dimension clevis pin for mechanical linkage and pivot assemblies requiring a 5/8 inch diameter pin with a 5/32 inch cotter hole.

Installation Notes

Installation requires no special tooling beyond a mallet or press to seat the pin and pliers to install the retaining cotter pin or clip. Ensure the receiving clevis jaws and bore are clean and free of burrs before insertion. Always install an appropriate cotter pin, hitch pin clip, or snap ring through the cross-hole to prevent the pin from walking out under load or vibration. De-energize or depressurize any connected system before servicing linkage hardware.
